AIRTEC Fiat 500 Abarth 60mm core Intercooler upgrade (Automatic Gearbox)

AIRTEC Fiat 500 Abarth 60mm core Intercooler upgrade (Automatic Gearbox)

AIRTEC Fiat 500 Abarth 60mm core Intercooler upgrade (Automatic Gearbox)

AIRTEC Fiat 500 Abarth 60mm core Intercooler upgrade (Automatic Gearbox)

Great addition to any standard or re-mapped 500’s

Fast Turbo spool up by using 50mm pipe-work into the turbo and 60mm out of the turbo to help match the throttle body, this combination gives fast turbo spool up and maximum power output

This intercooler will fit with the automatic paddle shift gearbox Fiat 500 Abarth.

AIRTEC part no: ATINTFT1/AUTO

Technical Data

Replaces very restrictive twin intercooler setup and lengthily pipe-work, for Airtec’s high flow 60mm core intercooler and shortened alloy pipe kit, we keep fast Turbo spool up by using 50mm pipe-work into the turbo and 60mm out of the turbo to help match the throttle body, this combination gives fast turbo spool up and maximum power output

Dyno test results – results taken from Fiat 500 Abarth Auto, with standard map, intercooler & exhaust results from AMD Essex.

Run 1.75 degree into the intercooler and 40 degree out of the intercooler – 168 BHP
Run 2.73 degree into the intercooler and 42 degree out of the intercooler – 166 BHP

Dyno test results – results taken from Fiat 500 Abarth Auto with AIRTEC FMIC, Miltek turbo back results from AMD Essex.

Run 1. 64 degree into the intercooler and 19 degree out of the intercooler
Run 2. 67 degree into the intercooler and 20 degree out of the intercooler
Run 3. 69 degree into the intercooler and 21 degree out of the intercooler

Features:

60mm thick proven bar and plate core, specced to Airtec design
Airtec logo’d Cast end tanks for improved Airflow and un-beatable stength
Dyno proven, gain BHP
Lower intake temps means safer engines ‘FACT’
Shorter charge pipes than standard twin intercooler set-up, short pipes mean fast turbo spool up
Fitting takes 2-3 hours
3 year un-limited mileage warranty
Available in Pro-Series satin Black or Natural Silver
Airtec Logo available @ no extra charge
Un-beatable value for money

This intercooler will fit with the automatic paddle shift gearbox Fiat 500 Abarth.

Select Hose Colour

Select Intercooler Finish

Select Airtec Logo Colour

From $339.85

Original: $1,132.82

-70%

AIRTEC Fiat 500 Abarth 60mm core Intercooler upgrade (Automatic Gearbox)—

$1,132.82

$339.85

More Images

AIRTEC Fiat 500 Abarth 60mm core Intercooler upgrade (Automatic Gearbox) - Image 2

AIRTEC Fiat 500 Abarth 60mm core Intercooler upgrade (Automatic Gearbox) - Image 3

AIRTEC Fiat 500 Abarth 60mm core Intercooler upgrade (Automatic Gearbox) - Image 4

AIRTEC Fiat 500 Abarth 60mm core Intercooler upgrade (Automatic Gearbox) - Image 5

AIRTEC Fiat 500 Abarth 60mm core Intercooler upgrade (Automatic Gearbox)

AIRTEC Fiat 500 Abarth 60mm core Intercooler upgrade (Automatic Gearbox)

Great addition to any standard or re-mapped 500’s

Fast Turbo spool up by using 50mm pipe-work into the turbo and 60mm out of the turbo to help match the throttle body, this combination gives fast turbo spool up and maximum power output

This intercooler will fit with the automatic paddle shift gearbox Fiat 500 Abarth.

AIRTEC part no: ATINTFT1/AUTO

Technical Data

Replaces very restrictive twin intercooler setup and lengthily pipe-work, for Airtec’s high flow 60mm core intercooler and shortened alloy pipe kit, we keep fast Turbo spool up by using 50mm pipe-work into the turbo and 60mm out of the turbo to help match the throttle body, this combination gives fast turbo spool up and maximum power output

Dyno test results – results taken from Fiat 500 Abarth Auto, with standard map, intercooler & exhaust results from AMD Essex.

Run 1.75 degree into the intercooler and 40 degree out of the intercooler – 168 BHP
Run 2.73 degree into the intercooler and 42 degree out of the intercooler – 166 BHP

Dyno test results – results taken from Fiat 500 Abarth Auto with AIRTEC FMIC, Miltek turbo back results from AMD Essex.

Run 1. 64 degree into the intercooler and 19 degree out of the intercooler
Run 2. 67 degree into the intercooler and 20 degree out of the intercooler
Run 3. 69 degree into the intercooler and 21 degree out of the intercooler

Features:

60mm thick proven bar and plate core, specced to Airtec design
Airtec logo’d Cast end tanks for improved Airflow and un-beatable stength
Dyno proven, gain BHP
Lower intake temps means safer engines ‘FACT’
Shorter charge pipes than standard twin intercooler set-up, short pipes mean fast turbo spool up
Fitting takes 2-3 hours
3 year un-limited mileage warranty
Available in Pro-Series satin Black or Natural Silver
Airtec Logo available @ no extra charge
Un-beatable value for money

This intercooler will fit with the automatic paddle shift gearbox Fiat 500 Abarth.

Product Information

Shipping & Returns

Description

AIRTEC Fiat 500 Abarth 60mm core Intercooler upgrade (Automatic Gearbox)

Great addition to any standard or re-mapped 500’s

Fast Turbo spool up by using 50mm pipe-work into the turbo and 60mm out of the turbo to help match the throttle body, this combination gives fast turbo spool up and maximum power output

This intercooler will fit with the automatic paddle shift gearbox Fiat 500 Abarth.

AIRTEC part no: ATINTFT1/AUTO

Technical Data

Replaces very restrictive twin intercooler setup and lengthily pipe-work, for Airtec’s high flow 60mm core intercooler and shortened alloy pipe kit, we keep fast Turbo spool up by using 50mm pipe-work into the turbo and 60mm out of the turbo to help match the throttle body, this combination gives fast turbo spool up and maximum power output

Dyno test results – results taken from Fiat 500 Abarth Auto, with standard map, intercooler & exhaust results from AMD Essex.

Run 1.75 degree into the intercooler and 40 degree out of the intercooler – 168 BHP
Run 2.73 degree into the intercooler and 42 degree out of the intercooler – 166 BHP

Dyno test results – results taken from Fiat 500 Abarth Auto with AIRTEC FMIC, Miltek turbo back results from AMD Essex.

Run 1. 64 degree into the intercooler and 19 degree out of the intercooler
Run 2. 67 degree into the intercooler and 20 degree out of the intercooler
Run 3. 69 degree into the intercooler and 21 degree out of the intercooler

Features:

60mm thick proven bar and plate core, specced to Airtec design
Airtec logo’d Cast end tanks for improved Airflow and un-beatable stength
Dyno proven, gain BHP
Lower intake temps means safer engines ‘FACT’
Shorter charge pipes than standard twin intercooler set-up, short pipes mean fast turbo spool up
Fitting takes 2-3 hours
3 year un-limited mileage warranty
Available in Pro-Series satin Black or Natural Silver
Airtec Logo available @ no extra charge
Un-beatable value for money

This intercooler will fit with the automatic paddle shift gearbox Fiat 500 Abarth.
